Theben THELEDA-D-UDL-AL 11W LED light THELEDA-D-UDL-AL
incl. 19% VAT
Delivery time:
1-3 Tage
Delivery time:
5-14 Tage
Article Category
Elektromaterial
>
Theben
>
Schütze & Schalter
Artikelnummer
4003468101186
Manufacturer Article Number
THELEDA-D-UDL-AL
Weight
0,87 kg
Design-focused 11 W LED luminaire, light emitted upwards (Up) and downwards (Down), high-quality housing made from anodised extruded aluminium profile, suitable for outdoor use, high IP 55 protection rating for outdoor installation, easy installation with plug-in base, wireless connectivity, extremely efficient thanks to high light output, long-lasting LEDs: 50,000-hour service life
| Suitable for platform or floor mounting | No |
|---|---|
| Luminous flux | 950 | 950 |
| Lamp luminous efficacy | 93 |
| Installation height/depth | - |
| Control unit | Not required |
| With control unit | Yes |
| Rated voltage | 230 | 230 |
| Material of the housing | Aluminium |
| Suitable for ceiling mounting | No |
| Suitable for busbar mounting | No |
| Dimming depends on the ballast | No |
| 1–10 V dimming | No |
| Phase-cut dimming | No |
| Zigbee dimming | No |
| Without a dimming function | No |
| Beam angle | Wide-angle 41–80° |
| With light sensor | No |
| Design life L80/B50 at 25 °C | 60000 |
| Protection class (NEMA) | 4 |
| Suitable for surface mounting | Yes |
| Suitable for mounting on a truss | No |
| Programmable dimming | No |
| Luminous intensity | - |
| Number of poles | 4 |
| Light bulbs | LED not replaceable |
| Case colour | Aluminium |
| Design life L70/B10 at 25 °C | - |
| Material of the cover | Transparent plastic |
| DMX dimming | No |
| Dimming potentiometer (built into the unit) | No |
| GPRS dimming | No |
| LineSwitch dimming | No |
| Phase-cut dimming | No |
| Energy efficiency class of the replaceable light source supplied | - |
| Lowest energy efficiency class of the replaceable light source | - |
| Energy Efficiency Index (EEI) for the electricity supply | Other |
| Total Harmonic Distortion (THD) | 27 |
| Design life L70/B50 at 25 °C | - |
| Suitable for clamp mounting | No |
| Design life L90/B10 at 25 °C | - |
| Design life L90/B50 at 25 °C | - |
| With a motion detector | No |
| Colour Rendering Index (CRI) | 80–89 |
| Version | Without |
| Impact resistance | IK04 |
| Installation length | - |
| Installation diameter | - |
| Conductor cross-sectional area | 2.5 |
| Connection type | Screw terminal |
| Suitable for use at a computer workstation in accordance with EN 12464-1 | - |
| Energy efficiency class of the built-in light source | A++, A+, A (LED) |
| Highest energy efficiency class for the replaceable light source | - |
| LED rated current at constant current | 0 | 10 |
| Max. system performance | 11 |
| Reflector | High-gloss |
| Light distribution | Symmetrical |
| Type of voltage | AC |
| Colour temperature | 3000 | 3000 |
| Suitable for rope systems | No |
| Adjustability | Not adjustable |
| Installation width | - |
| Connectable conductor cross-section | 0 | 2.5 |
| The light fitting can be covered with thermal insulation material | No |
| Type of wiring | Conclusion |
| Suitable for pendulum suspension | No |
| RF dimming | No |
| Touch and Dim dimming | No |
| Dimming with a push-button | No |
| Rated ambient temperature in accordance with IEC 62722-2-1 | -25 | 45 |
| Power factor | 0.95 |
| Glow-wire test in accordance with IEC 60695-2-11 | 650 °C – 30 s |
| Photobiological safety in accordance with EN 62471 | RG0 |
| Colour consistency (McAdam ellipse) | SDCM6 |
| Light diffuser | Reflector |
| Light output | Direct/indirect |
| Suitable for flush-mounted installation | No |
| Surface protection | Powder-coated |
| Brushed finish | Yes |
| "Lamp with a limited surface temperature – 'D-mark' " | No |
| Rated luminous flux in accordance with IEC 62722-2-1 | 950 |
| Suitable for the number of light sources | - |
| 0–10 V dimming | No |
| DALI dimming | No |
| DSI dimming | No |
| Dimming Sine Wave Reduction | No |
| Light colour | White |
| Length | 65 |
| Width | 126 |
| Height/Depth | 224 |
| Outer diameter | - |
| Protection class | II |
| Protection class (IP) | IP55 |
| With a light source | Yes |
| Suitable for lamp wattage | - |
| Design life L80/B10 at 25 °C | - |
| Suitable for wall mounting | Yes |
| Luminaire luminous efficacy | 93 |
| Dimming varies by manufacturer | Yes |
| Dimming: Mains voltage modulation | No |
